Description

FRAME COR XC Philosophy, FOC Ultra Carbon Frame,
110mm Travel Independent Drivetrain¬ 27.5 AOS
Suspension System w/Forged Linkage, Pivots,
1 1/8″-1 1/2″ Integrated Head Tube, and
12 x 142mm Maxle Dropouts

FORK Fox 32 FLOAT 27.5 CTD Remote FIT, 110mm
Travel, 15QR, w/FIT Damper, Remote Lockout &
Rebound Adjust, Tapered Alloy Steerer

REAR SHOCK Fox Racing Shox Float CTD Remote BV, 6.5″x1.5″
Air Shock, w/ Rebound Adjust & Remote Lockout

CHAIN DEVICE (F) e.thirteen XCX+ High Direct Mount,

CRANKSET RaceFace Turbine Basic, 32T Narrow Wide

BOTTOM BRACKET RaceFace

PEDALS N/A

DERAILLEUR (R) Shimano Deore XT Shadow Plus, Direct
Mount, RD-M786-D, GS Cage

SHIFTERS Shimano Deore XT, SL-M780, Rapid Fire,
Right Side Only

REAR COGS Shimano Deore XT, CS-M771-10, 10-Speed,
11-36T

CHAIN KMC X10

RIMS Stan’s NoTubes Crest, ZTR Tubeless, 32H

TYRES (F) Continental X-King 27.5×2.2″, Folding,
(R) Continental X-King 27.5×2.2″, Folding

HUBS (F) DT Swiss 350, Centerlock, 15x100mm Thru
Axle, (R) DT Swiss 350, Centerlock, 12x142mm
Thru Axle

SPOKES DT Competition, 1.8/1.6 Stainless, Black

NIPPLES DT Alloy

BRAKES (F) Shimano Deore XT, BR-M785 w/Metallic Pad,
180mm SM-RT81 Centerlock IceTech Rotor,
(R) Shimano Deore XT, BR-M785 w/Metallic Pad,
180mm SM-RT81 Centerlock IceTech Rotor

BRAKE LEVERS Shimano Deore XT, BL-M785

HANDLEBARS RaceFace Turbine 35, 740mm Width, 10mm Rise

STEM RaceFace Turbine 35, 1 1/8″ Threadless, 0¬∞ Rise,
35mm Clamp, 80mm

GRIPS GT Statement Single Lock-on Grips

HEADSET Orbit C-40-ACB

SADDLE fizik Tundra2, Manganese Rail

SEAT POST RaceFace Turbine, 31.6x375mm
